Hydraulic Gorilla Rock Hammer GX155/GXS155- 10,000 lb
from
$ 700.00
per
day
Description
| Medium to Heavy Duty | Unit | GX155/ GXS155 |
| Impact Energy
Comparison CIMA Ratings available upon request
|
ft. lbs | 8,000 |
| Operating weight | ||
| GX Series (Side plated) | lb | 6,900 |
| kg | 3,130 | |
| GXS Series (Low noise box type) | lb | 6,500 |
| kg | 2,950 | |
| Blows per minute | bpm | 300-600 |
| Tool diameter | inch | 6.1 |
| mm | 155 | |
| Weight of carrier (min-max) | ton | 30-35 |
| lbs | 66,130- 77,162 |
|
| Height with tool (with top bracket) | ||
| GXS Series Low Noise box type | inch | 127.5 |
| mm | 3,236 | |
| GX Series side plate type | inch | 128.0 |
| mm | 3,251 | |
| Noise at 85dB(A), radius | ||
| GXS Series Low Noise box type | m | 17 |
| GX Series side plate type | m | 28 |
| Oil Flow Rate | gallons per minute | 50-66 |
| liters per minute | 190-250 | |
| Operating oil pressure | psi | 2,300- 2,600 |
| bar | 160-180 | |
| Aux. circuit relief (cracking) | psi | 3,100 |
| bar | 220 | |
| Maximum return pressure | psi | 215 |
| kgf/cm2 | 15 | |
| Oil hose diameter | inch | 1 1/4 |
| mm | 32 | |
